Integra DPS-6.5 - Printed Circuit Board Parts List

2/8PAGE
EXP
Z104 SCREW 3SMS8W.SW+14B(BC) 4 801433
EXP
Z106 IB CUSHION W15x3t TAPE 1 28141585 MP0081:CM
EXP
Z107 CUSHION (DAC) 2 28141445
DPS-6.5
PRINTED CIRCUIT BOARD PARTS LIS
T
<Notes>
U01 FRONT DISPLAY PC BOARD(NADIS-8416-1G/1H) ! :Safety parts
U02 STANDBY LED PC BOARD(NADIS-8417-1G/1H) <MDD> :North American area
U03 AUDIO/VIDEO OUTPUT PC BOARD(NAAR-8419-1G/1H) <MUA> :Australia area
U04 INLET TERMINAL PC BOARD(NAPS-8420-1G/1H)
REF. NO. NAME DESCRIPTION Q'TY PART NO REMARKS
PCB
Q501 IC MPD4721GS 1 22241537R2
<MDD>
PCB
Q501 IC MPD4721GS 1 22241537R2
<MUA>
PCB
Q502 IC
MPD789071MC
-
011
-
5A4
1 22241624R2
<MDD>
PCB
Q502 IC
MPD789071MC
-
011
-
5A4
1 22241624R2
<MUA>
PCB
Q503 IC TC74VHCT32AFT 1 22274032GR2TO
<MDD>
PCB
Q503 IC TC74VHCT32AFT 1 22274032GR2TO
<MUA>
PCB
Q504 IC BA7664AFV 1 22242164R2
<MDD>
PCB
Q504 IC BA7664AFV 1 22242164R2
<MUA>
PCB
Q505 PHT CP ON3131 1 24120043
<MDD>
PCB
Q505 PHT CP ON3131 1 24120043
<MUA>
PCB
Q506 TR KRC102S 1 2216190R2
<MDD>
PCB
Q506 or TR RN1402 ( 1) 2214470R2
<MDD>
PCB
Q506 or TR DTC114EKA ( 1) 2216250R2
<MDD>
PCB
Q506 TR KRC102S 1 2216190R2
<MUA>
PCB
Q506 or TR RN1402 ( 1) 2214470R2
<MUA>
PCB
Q506 or TR DTC114EKA ( 1) 2216250R2
<MUA>
PCB
Q507 TR KRC102S 1 2216190R2
<MDD>
PCB
Q507 or TR RN1402 ( 1) 2214470R2
<MDD>
PCB
Q507 or TR DTC114EKA ( 1) 2216250R2
<MDD>
PCB
Q507 TR KRC102S 1 2216190R2
<MUA>
PCB
Q507 or TR RN1402 ( 1) 2214470R2
<MUA>
PCB
Q507 or TR DTC114EKA ( 1) 2216250R2
<MUA>
PCB
Q508 IC(REGULATOR)
78M05HF(NJM78M05D
L1A TE1)
1 222780055R2JR
<MDD>
PCB
Q508 IC(REGULATOR)
78M05HF(NJM78M05D
L1A TE1)
1 222780055R2JR
<MUA>
PCB
Q509 TR KRC107S 1 2216340R2
<MDD>
PCB
Q509 or TR RN1407 ( 1) 2216260R2
<MDD>
PCB
Q509 or TR DTC114YKA ( 1) 2216470R2
<MDD>
PCB
Q509 TR KRC107S 1 2216340R2
<MUA>
PCB
Q509 or TR RN1407 ( 1) 2216260R2
<MUA>
PCB
Q509 or TR DTC114YKA ( 1) 2216470R2
<MUA>
PCB
Q701 IC MPD780232GC-709-8BT 1 22242204R3
PCB
Q702 FL TUBE HNV-13SS15T 1 212253
PCB
Q702A CUSHION t3x10x25 2 28141513
PCB
Q704 IC S-80127CNMC-JKM-T2 1 22241642R2
PCB
Q706 TR 2SD655-E 1 2211705
PCB
Q706 or TR 2SD655-F ( 1) 2211706
PCB
Q707 REMO SENS RPM7238-H9 1 241355
PCB
Q708 TR KRC107S 1 2216340R2
PCB
Q708 or TR RN1407 ( 1) 2216260R2
PCB
Q708 or TR DTC114YKA ( 1) 2216470R2
PCB
Q709 TR KRA107S 1 2216350R2
PCB
Q709 or TR RN2407 ( 1) 2216360R2
PCB
Q709 or TR DTA114YKA ( 1) 2216480R2
PCB
Q710 TR KRA107S 1 2216350R2
PCB
Q710 or TR RN2407 ( 1) 2216360R2
PCB
Q710 or TR DTA114YKA ( 1) 2216480R2
PCB
Q711 TR KRC107S 1 2216340R2
PCB
Q711 or TR RN1407 ( 1) 2216260R2
PCB
Q711 or TR DTC114YKA ( 1) 2216470R2
PCB
Q714 TR KRC107S 1 2216340R2
PCB
Q714 or TR RN1407 ( 1) 2216260R2
