Appendix
Audio Inputs North American models Australian models
Analog 8 (Including 1×PHONO, 1×AUX(Front))
Digital 2 (COA XI A L×1, O PT I CA L×1)
Audio Outputs North American models Australian models
Analog
LINE OUT (ZONE 2)(*) × 1
PRE OUT (FRONT L/R, CENTER, SURROUND L/R, HEIGHT 1 L/R, SURROUND BACK L/R or HEIGHT 2 L/R
or ZONE 3) × 1
PRE OUT (SUBWOOFER) × 2
*Can be changed to PRE OUT(ZONE 2) or LINE OUT (ZONE B).
Speaker Outputs
11 (FRONT L/R, CENTER, SURROUND L/R, HEIGHT 1 L/R or ZONE 2 L/R, SURROUND BACK L/R or ZONE 3
L/R or HEIGHT 2 L/R)
• North American models are banana plug ready.
Phones 1 (ø 6.3 mm, 1/4")
Others North American models Australian models
Setup Mic 1 (Front)
RS-232 1
12V TRIGGER OUT 3 (A:100 mA, B:25 mA, C:25 mA)
IR IN × 2(A/B), OUT × 1
Specications and features are subject to change without notice.
