Integra DRX-3.4 - Page 35

5.1.2ch
7.1. 2c h
5.1.4ch
7.1ch
5.1ch
35
Speaker Connections
 5.1 Channel System + ZONE SPEAKER
FL(Z3)FR(Z3)
FL FR
SL SR
C
SW
SW FR FL C
SR SL
FR(Z2) FL(Z2) FR(Z3) FL(Z3)
Zone 2
FL(Z2)FR(Z2)
Main Room
Zone 3
To output audio from an externally connected AV component to ZONE 3, use an analog audio cable for connection. Note that ZONE 3 output is not possible with the
connection using a HDMI cable, digital coaxial cable, or digital optical cable.
