Controls, Indicators and operation
- 5 -
English
Microphone
22. PTT (Push-to-Talk) Key
Transmitter key. Press the PTT (22) key to transmit and release it to return to the receive mode.
23. MICROPHONE Plug
6-pole microphone plug with locking ring nut, to be connected to the microphone connector (17) located on the front side
of the radio.
22
23
WARNING !
Do never try to open the cabinet of the radio. No user serviceable parts are inside the cabinet. Tampering or
modifying the circuit of the radio or its original factory adjustment may cause damage to the product, may change
the electrical specifications and will void the warranty. If service is required, please refer only to a qualified and
authorized service center.
