Model No: Drawing No:
C9
7P(03)
Capacitor Ceramic 0603 NP0 1
C90 680P Capacitor Chip X7R 0402 1
C91 270P(NPO) Capacitor Chip NPO 0402 1
C92 0.0022 Capacitor Chip X7R 0402 1
C93 0.015 Capacitor Chip X7R 0402 1
C94 0.1 Capacitor Chip Y5V 0402 1
C95 0.1 Capacitor Chip Y5V 0402 1
C96 0.1 Capacitor Chip Y5V 0402 1
C97
220P(NPO)
Capacitor Chip NPO 0402 1
C98 0.1 Capacitor Chip Y5V 0402 1
C99 0.015 Capacitor Chip X7R 0402 1
CF1 21.4MHZ X-tal filter 21.4MHz UM-5 1
CF2 CF450KHz 450KHz IFT 5mm 1
CF3 LTM450GU Ceramic filter LTM450GU 1
CMIC1 F9745AP342-34 Condensor Mic 1
CPU1 W742S81A-XXXXX IC CPU 1
CT201 10P (Trimmer) 3 dia STC3M10-T1 1
CX201 4 MHz X-tal D4.00C(20pF) HS-49/S 1
D1 KDS114E Diode Switching 1
D10 KDS114E Diode Switching 1
D13 KDS114E Diode Switching 1
D2 KDS121 CHIP DIODE 1
D3 KDS114E Diode Switching 1
D301 KDS114E Diode Switching 1
D302 KDV154B Diode Vari-cap 1
D5 KDS114E Diode Switching 1
D6 KDS113E Diode Switching 1
D7 KDS112 Diode Chip 1
D8 KDS112 Diode Chip 1
D9 KDS114E Diode Switching 1
IC1 S5018 IC IF 1
IC2 AZ386M IC Speaker 1
IC201 TB31202 IC PLL 1
IC3 XC6201 IC Regulator 4V 1
IC4 S324 IC OP 1
IC5 S324 IC OP 1
IC6 XC61CN2402MR 2.4Vdc Detector IC 1
J9-A EXT MIC Jack Dual LT2510C 1
L1 0.35X1.7X5T(R) Inductor Air 1
L10 27NH(03) Inductor Chip 0603 1
L11 0.35X1.8X5T(R) Inductor Air 1
Created by: Approved by: Rev. No:
For Stage : Release Date : Page 32 of 49
