Model No: Drawing No:
L12 5.6UH(05) Inductor Chip 0805 1
L13 220NH(03) Inductor Chip 0603 1
L14 18NH Inductor Chip 0402 1
L15 0.3X1.4X6T(R) Inductor Air 1
L16 100NH Inductor Chip 0402 1
L18 0.3X1.0X3T(R) Inductor Air 1
L2 10UH(05) Inductor Chip 0805 1
L3 0.3X1.4X6T(R) Inductor Air 1
L302 2.2UH(03) Inductor Chip 0603 1
L303 0.3X1.1X4T(R) Inductor Air 1
L4 47NH Inductor Chip 0402 1
L5 33NH Inductor Chip 0402 1
L6
0.4X1.1X2T(R)
Inductor Air 1
L7 0.35X1.8X5T(R) Inductor Air 1
L8 0.4X1.5X5T(L) Inductor Air 1
L9 27NH(03) Inductor Chip 0603 1
LCD1 LCD GX-XXXXX 1
LED1 LTST-S320GKT Diode LED SMT 1
LED2 DUAL_LED KPBA-3010ESGC 1
PCB1 PCB 4 Layer for MT4040D 1
Q1 NE5510279A Transistor Chip 1
Q10 KRA306E Transistor BRT 1
Q11 BFQ67W Transistor Chip 1
Q12 KRC404E Transistor BRT 1
Q13 KTA1505S Transistor BRT 1
Q14 KRA306E Transistor BRT 1
Q16 KRA226S Transistor BRT 1
Q17 KRC405E Transistor BRT 1
Q18 KRA226S Transistor BRT 1
Q19 KRC401E Transistor BRT 1
Q2
BFQ67W
Transistor Chip 1
Q21 KTC4075E Transistor Chip 1
Q22 KTC4075E Transistor Chip 1
Q23 KRC405E Transistor BRT 1
Q24 KRC404E Transistor BRT 1
Q25 KRC405E Transistor BRT 1
Q26 KRA304E Transistor BRT 1
Q27 KRC404E Transistor BRT 1
Q3 KRC405E Transistor BRT 1
Q301 2SC4226 Transistor Chip 1
Q302 2SC4226 Transistor Chip 1
Created by: Approved by: Rev. No:
For Stage : Release Date : Page 33 of 49
