8XC196KC/8XC196KC20
DATA SHEET REVISION HISTORY
This data sheet is valid for devices with a ‘‘H’’, ‘‘L’’ or ‘‘M’’ at the end of the topside tracking number. The
topside tracking number consists of nine characters and is the second line on the top side of the device. Data
sheets are changed as new device information becomes available. Verify with your local Intel sales office that
you have the latest version before finalizing a design or ordering devices.
The following are differences between the 270942-004 and 270942-005 datasheets:
1. Removed ‘‘Word Addressable Only’’ from Port 3 and 4 in Table 2.
2. Renamed PVAL to CPVER.
3. Removed T
LLYV
and T
LLGV
from the waveform diagrams.
4. Added HSI
Ð
MODE divide-by-eight and IPD hump to 8XC196KC errata.
The following are important differences between the 270942-002 and 270942-004 data sheets:
1. NMI during PTS, QBD port glitch and Divide HOLD/READY erratas were fixed and have been removed
from the data sheet. The HSI errata is also removed as this is now considered normal operation.
2. Combined 16 and 20 MHz data sheets. Data sheet 270924-001 (20 MHz) is now obsolete.
3. Added 80-lead SQFP package pinout.
4. Added documentation for CLKOUT disable bit.
5. i
JA
for QFP package was changed to 55
§
C/W from 42
§
C/W.
6. i
JC
for QFP package was changed to 16
§
C/W from TBD
§
C/W.
7. T
SAM
(MIN) in 10-bit mode was changed to 1.0 ms from 3.0 ms.
8. T
SAM
(MIN) in 8-bit mode was changed to 1.0 ms from 2.0 ms.
9. I
IL1
specification for port 2.0 was renamed I
IL2
.
10. I
IL2
(MAX) is changed to TBD from
b
6 mA.
11. I
IH1
(MAX) is changed to
a
200 mA from
a
100 mA.
12. I
IH1
test condition changes to V
IN
e
2.4V from V
IN
e
5.5V.
13. V
HYS
is changed to 300 mV from 150 mV.
14. I
CC
(TYP) at 16 MHz is changed to 65 mA from 50 mA.
15. I
CC
(MAX) at 16 MHz is changed to 75 mA from 70 mA.
16. I
CC
(TYP) at 20 MHz is changed to 80 mA from 60 mA.
17. I
CC
(MAX) at 20 MHz is changed to 92 mA from 86 mA.
18. I
IDLE
(TYP) at 16 MHz is changed to 17 mA from 15 mA.
19. I
IDLE
(MAX) at 16 MHz is changed to 25 mA from 30 mA.
20. I
IDLE
(TYP) at 20 MHz is changed to 21 mA from 15 mA.
21. I
IDLE
(MAX) at 20 MHz is changed to 30 mA from 35 mA.
22. I
PD
(TYP) at 16 MHz is changed to 8 mA from 15 mA.
23. I
PD
(MAX) at 16 MHz is changed to 15 mA from TBD.
24. I
PD
(TYP) at 20 MHz is changed to 8 mA from 18 mA.
25. I
PD
(MAX) at 20 MHz is changed to 15 mA from TBD.
26. T
CLDV
(MAX) is changed to T
OSC
b
45 ns from T
OSC
b
50 ns.
27. T
LLAX
(MIN) is changed to T
OSC
b
35 ns from T
OSC
b
40 ns.
28. T
CHWH
(MIN) is changed to
b
5 ns from
b
10 ns.
29. T
RHAX
(MIN) is changed to T
OSC
b
25 ns from T
OSC
b
30 ns.
30. T
HALAZ
(MAX) is changed to
a
15 ns from
a
10 ns.
31. T
HALBZ
(MAX) is changed to
a
20 ns from
a
15 ns.
