8XC196KC/8XC196KC20
32. T
HAHBV
(MAX) is now specified at
a
15 ns, was formerly unspecified.
33. The T
LLYV
and T
LLGV
specifications were removed. These specifications are not required in high-speed
systems designs.
34. Added EXTINT, P0.7 errata to Errata section.
The following are the important differences between the -001 and -002 versions of data sheet 270942.
1. Express and Commercial devices are combined into one data sheet. The Express only data sheet
270794-001 is obsolete.
2. Removed KB/KC feature set differences, pin definition table, and SFR locations and bitmaps.
3. Added programming pin function to package drawings and pin descriptions.
4. Changed absolute maximum temperature under bias from 0
§
Cto
a
70
§
Cto
b
55
§
Cto
a
125
§
C.
5. Replaced V
OH2
specification with I
OH1
and I
IL1
specifications.
6. Added I
IH1
specification for NMI pulldown resistors.
7. Added maximum hold latency table.
8. Added external oscillator and external clock circuit drawings.
9. Changed Clock Drive T
XHXX
and T
XLXX
Min spec to 20 ns.
10. Fixed Serial Port T
XLXH
specification.
11. Added 8- and 10-bit mode A/D operating conditions tables.
12. Specified operating range for sample and convert times.
13. Added specification for voltage on analog input pin.
14. Put operating conditions for EPR OM programming into tabular format.
25
