Desktop Board Features
13
Table 2. Intel Desktop Board DH67CL Components
Label Description
A Conventional PCI bus connector
B Conventional PCI bus connector
C Conventional PCI bus connector
D PCI Express 2.0 x1 add-in card connector
E PCI Express 2.0 x1 add-in card connector
F PCI Express 2.0 x16 add-in card connector
G Back panel connectors
H 12 V processor core voltage connector (2 x 2 pin)
I Rear chassis fan header
J Processor socket
K Processor fan header
L DDR3 DIMM 3 socket
M DDR3 DIMM 1 socket
N DDR3 DIMM 4 socket
O DDR3 DIMM 2 socket
P Front chassis fan header
Q Chassis intrusion header
R Front panel CIR receiver (input) header
S Back panel CIR emitter (output) header
T Main power connector (2 x 12 pin)
U Battery
V Speaker
W SATA connectors
X Alternate front panel power LED header
Y Front panel header
Z BIOS configuration jumper block
AA Standby power indicator LED
BB Front panel USB 2.0 headers
CC S/PDIF header
DD Front panel audio header
