Intel Desktop Board DP55KG Product Guide
56
Connecting Chassis Fan and Power Supply
Cables
Connecting Chassis Fan Cables
Connect chassis fan cables to the chassi
s fan headers on the Desktop Board.
Figure 29 shows the location of
the chassis fa
n headers.
Figure 29. Location of t
he Chassis Fan Headers
55
57
