Intel Desktop Board D2500HN Technical Product Specification
14
Table 3. Board Components Shown in Figure 1
Item/callout
from Figure 1 Description
A
Back panel connectors
B
Standby power LED
C
Processor core power connector (2 x 12)
D
Intel Atom processor
E
SO-DIMM channel A DIMM 1 socket
F
SO-DIMM channel A DIMM 0 socket
G
Intel NM10 Express Chipset
H
SATA connectors
I
System fan header
J
Front panel header
K
Battery
L
Front panel USB 2.0 header
M
BIOS setup configuration jumper block
N
Piezo/monotonic speaker header
O Conventional PCI bus add-in card connector
P
S/PDIF header
Q
Front panel audio header
R Front panel USB 2.0 header
S
Serial port header, COM 1
