Intel Desktop Board D410PT Technical Product Specification
66
3.6.2 Custom Splash Screen
During POST, an Intel
®
splash screen is displayed by default. This splash screen can
be augmented with a custom splash screen. The Intel
®
Integrator’s Toolkit that is
available from Intel can be used to create a custom splash screen.
NOTE
If you add a custom splash screen, it will share space with the Intel branded logo.
For information about
Refer to
Intel Integrator Toolkit http://developer.intel.com/design/motherbd/software/itk/
3.7 Boot Options
In the BIOS Setup program, the user can choose to boot from optical drives, hard
drives, removable media or the network. The default setting is for the optical drive to
be the first boot device, the hard drive second, and removable media third. If
enabled, the last default boot device is the network.
3.7.1 CD-ROM Boot
Booting from CD-ROM is supported in compliance to the El Torito bootable CD-ROM
format specification. Under the Boot menu in the BIOS Setup program, ATAPI
CD-ROM is listed as a boot device. Boot devices are defined in priority order.
Accordingly, if there is not a bootable CD in the CD-ROM drive, the system will attempt
to boot from the next defined drive.
3.7.2 Network Boot
The network can be selected as a boot device. This selection allows booting from the
onboard LAN or a network add-in card with a remote boot ROM installed.
Pressing the <F12> key during POST automatically forces booting from the LAN. To
use this key during POST, the User Access Level in the BIOS Setup program's Security
menu must be set to Full.
