Intel Desktop Board D865GSA Product Guide
34
Removing DIMMs
To remove a DIMM, follow these steps:
1. Observe the precautions in "Before You Begin" on page 23.
2. Turn off all peripheral devices connected to the computer. Turn off the computer.
3. Remove the AC power cord from the computer.
4. Remove the computer’s cover.
5. Gently spread the retaining clips at each end of the DIMM socket. The DIMM pops out of
the socket.
6. Hold the DIMM by the edges, lift it away from the socket, and store it in an anti-static package.
7. Reinstall and reconnect any parts you removed or disconnected to reach the DIMM sockets.
8. Replace the computer’s cover and reconnect the AC power cord.
Installing and Removing an AGP Card
CAUTION
When installing an AGP card on the desktop board, ensure that the card is fully seated in the
connector before you power on the system. If the card is not fully seated in the connector, an
electrical short may result across the connector pins. Depending on the over-current protection of
the power supply, certain desktop board components and/or traces may be damaged.
Installing an AGP Card
1. Observe the precautions in "Before You Begin" on page 23.
2. Place the card in the AGP connector (Figure 16, A) and press down on the card until it is
completely seated in the connector and the card retention notch snaps into place around the
retention mechanism pin on the connector.
3. Secure the card’s metal bracket to the chassis back panel with a screw (Figure 16, B).
