Connecting Internal Headers
Before connecting cables to the internal headers, observe the precautions in "Before You Begin" on
page 23. Figure 20 shows the location of the internal headers.
OM19182
C
10
87
65
4
2
1
3
No
Connection
Ground
D+
D–
Power (+5 V)
Key (no pin)
Ground
D+
Power (+5 V)
D–
A
B
D
+5 V
Reset
HD LED
On/Off
Power
LED
1
9
87
65
4
2
3
109
7
65
4
2
1
3
AUD–RET–L
KEY
AUD–RET–R
AUD–VCC
AUD–GND
AUD–FPOUT–L
HP–ON
AUD–FPOUT–R
AUD–MIC–BIAS
AUD–MIC
4
3
2
1
Left Audio Input
Audio Ground
Audio Ground
Right Audio Input
Item Description
A Front panel audio
B CD-ROM audio
C USB 2.0
D Front panel
Figure 20. Internal Headers
