Desktop Board D945PWM Specification Update
5
SPECIFICATION CHANGES
The Specification Changes listed in this section apply to the Desktop Board D945PWM Technical
Product Specification (Order Number D44275). All Specification Changes will be incorporated
into a future version of that specification.
1. The following note will be added to the Technical
Product Specification in Section 2.8.2.3 Add-in Card
Connectors:

NOTE
Capacitors required for the audio circuitry are located within the ATX keep-out area near PCI
Express* x1 slot 1, and may limit the use of some PCI Express x1 cards.
2. The following note will be added to the Technical
Product Specification in Section 1.9.2 Audio Connectors:
 INTEGRATOR’S NOTES
Electrostatic discharge (ESD) can damage desktop board
components. Front-panel connectors should provide sufficient
protection to prevent ESD damage to components inside the chassis
enclosure.
