1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the Intel Desktop Board DG41TY.
Table 1. Feature Summary
Form Factor Micro-ATX (9.60 inches by 8.60 inches [243.84 millimeters by 218.44 millimeters])
Processor Support for the following:
• Intel
®
Core™2 Quad processor in an LGA775 socket
• Intel
®
Core™2 Duo processor in an LGA775 socket
• Intel
®
Pentium
®
Dual-Core processor in an LGA775 socket
• Intel
®
Celeron
®
Dual-Core processor in an LGA775 socket
• Intel
®
Celeron
®
processor Sequence 400 in an LGA775 socket
Memory
• Two 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR2 667 MHz or DDR2 800 MHz DIMMs
• Support for up to 8 GB of system memory
Chipset
Intel
®
G41 Express Chipset, consisting of:
• Intel
®
82G41 Graphics and Memory Controller Hub (GMCH)
• Intel
®
82801GB I/O Controller Hub (ICH7)
Video Intel
®
Graphics Media Accelerator X4500 (Intel
®
GMA X4500) onboard graphics
subsystem
Audio 5.1+2-channel audio subsystem using the Realtek* ALC888VC audio codec
Legacy I/O
Control
Legacy I/O controller for serial and PS/2* ports
Peripheral
Interfaces
• Eight USB 2.0 ports: four back panel connectors and four front panel headers
• Four Serial ATA (SATA) interfaces
• One Parallel ATA IDE interface with UDMA 33, ATA-66/100 support
• PS/2 keyboard and mouse ports
• Diskette drive connector
• One serial port header (may require specialized chassis or cable for use)
LAN Support 10/100/1000 Mbits/sec LAN subsystem using Realtek RTL8111D Gigabit Ethernet
Controller
BIOS
• Intel
®
BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly
Available PC
Technology
• Support for PCI* Local Bus Specification Revision 2.3
• Support for PCI Express* Revision 1.1
• Suspend to RAM support
• Wake on PCI, RS-232, front panel, PS/2 devices, and USB ports
continued
