Intel Desktop Board DG45ID Product Guide
12
Table 2. Desktop Board DG45ID Components
Label Description
A Front panel audio header
B PCI bus connector
C PCI Express x1 connector 2
D PCI Express x16 connector
E PCI Express x1 connector 1
F Rear chassis fan header (3-pin)
G Back panel connectors
H Back panel CIR emitter (output)
I 12 V processor core voltage connector (2 x 2 pin)
J Serial header
K Processor socket
L Processor fan header (4-pin)
M Front panel CIR receiver (input)
N Main power connector (2 x 12 pin)
O DDR2 DIMM 0 sockets
P DDR2 DIMM 1 sockets
Q Front chassis fan header (3-pin)
R Battery
S Chassis intrusion header
T Alternate front panel power LED header
U Front panel header
V BIOS configuration jumper block
W Serial ATA connectors (5)
X Speaker
Y High-speed USB 2.0 headers (3)
Z IEEE 1394a header
AA HD audio link header
BB S/PDIF header
For more information about Intel Desktop Board DG45ID, go to
http://intel.com/design/motherbd.
