Desktop Board Features
17
Table 3. Audio Jack Retasking Support
Jack Mic Line out Head-phones
Line in/Side
Surround
Rear
Surround
Center/
Subwoofer
Front Panel
Green No Yes Yes No No No
Pink Yes No No No No No
Back Panel
Blue No No No Yes No No
Green No Yes Yes No No No
Pink Yes No No No No No
Black No No No No Yes No
Orange No No No No No Yes
Legacy Input/Output (I/O) Controller
The I/O controller features the following:
• Low pin count (LPC) interface
• One serial port interface via an onboard header
• Consumer Infrared (CIR) support
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• Intelligent power management, including a programmable wake up event interface
• PCI power management support
LAN Subsystem
The LAN subsystem includes:
• Intel
®
ICH10R
• Intel 82567LF Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
• RJ-45 LAN connector with integrated status LEDs
The subsystem features:
• CSMA/CD protocol engine
• LAN connect interface between ICH10R and the LAN controller
• PCI Express power management
For information about LAN software and drivers go to
http://support.intel.com/support/motherboards/desktop
LAN Subsystem Software
For LAN software and drivers, refer to the DG45ID link on Intel’s World Wide Web site
at http://support.intel.com/support/motherboards/desktop
.
