Intel DH61BE User Manual

Error Messages and Beep Codes
73
Table 41. Port 80h POST Codes (continued)
Port 80 Code Progress Code Enumeration
Removable Media
0xB8 Resetting removable media
0xB9 Disabling removable media
0xBA Detecting presence of a removable media (IDE, CDROM detection
etc.)
0xBB Enabling/configuring a removable media
DXE Core
0xE4 Entered DXE phase
BDS
0xE7 Waiting for user input
0xE8 Checking password
0xE9 Entering BIOS setup
0xEB Calling Legacy Option ROMs
Runtime Phase/EFI OS Boot
0xF8 EFI boot service ExitBootServices( ) has been called
0xF9 EFI runtime service SetVirtualAddressMap( ) has been called

Intel DH61BE Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
PCI Express x16	1
PCIe 2.0 x1 Slots	2
SATA Ports	4
RAID Support	No
Ethernet	10/100/1000 Mbps
Onboard Video	Yes
Video Output	DVI, VGA
