Intel DH67VR

Desktop Board Features
13
Table 2. Intel Desktop Board DH67VR Components
Label Description
A PCI bus connector
B PCI Express 2.0 x1 add-in card connector
C PCI Express 2.0 x1 add-in card connector
D PCI Express 2.0 x16 add-in card connector
E Back panel connectors
F 12 V processor core voltage connector (2 x 2 pin)
G Rear chassis fan header
H Processor socket
I Processor fan header
J DDR3 DIMM 3 socket
K DDR3 DIMM 1 socket
L DDR3 DIMM 4 socket
M DDR3 DIMM 2 socket
N Front chassis fan header
O Chassis intrusion header
P Front panel CIR receiver (input) header
Q Back panel CIR emitter (output) header
R Main power connector (2 x 12 pin)
S Battery
T Speaker
U SATA connectors
V Front panel header
W Alternate front panel power LED header
X BIOS configuration jumper block
Y Front panel USB 2.0 headers
Z Standby power indicator LED
AA S/PDIF header
BB Front panel audio header
