Desktop Board Features
19
Table 4. LAN Connector LEDs
LED LED Color LED State Indicates
A (Link/Activity) Off LAN link is not established
Green
On LAN link is established
Blinking LAN activity is occurring
N/A Off 10 Mb/s data rate
Green On 100 Mb/s data rate
B (Link Speed)
Yellow On 1000 Mb/s data rate
USB Support
The Desktop Board supports USB 3.0 and USB 2.0. USB 3.0 is supported via two
USB 3.0 ports (blue) on the back panel. USB 3.0 ports are backward compatible with
USB 2.0 and USB 1.1 devices. The USB 3.0 ports are SuperSpeed, high-speed, full-
speed, and low-speed capable. USB 3.0 support requires both an operating system
and drivers that fully support USB 3.0 transfer rates.
There are 12 USB 2.0 ports (four ports routed to back panel connectors (black) and
eight ports routed to four onboard headers). The USB 2.0 ports are high-speed, full-
speed, and low-speed capable. USB 2.0 support requires both an operating system
and drivers that fully support USB 2.0 transfer rates.
SATA Support
Intel Desktop Board DH67VR provides two onboard 6.0 Gb/s Serial ATA (SATA)
channels.
Expandability
Intel Desktop Board DH67VR provides the following connectors for system expansion:
• One PCI Express 2.0 x16 connector
• Two PCI Express 2.0 x1 connectors
• One PCI bus connector
