Intel Desktop Board DP67BA Technical Product Specification
14
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A PCI Conventional bus add-in card connector
B PCI Conventional bus add-in card connector
C PCI Conventional bus add-in card connector
D PCI Express x1 bus add-in card connector
E IEEE 1394a front panel header
F PCI Express x1 bus add-in card connector
G PCI Express x16 bus add-in card connector
H Back panel connectors
I Processor core power connector (2 x 2)
J Rear chassis fan header
K LGA1155 processor socket
L Processor fan header
M DIMM 3 (Channel A DIMM 0)
N DIMM 1 (Channel A DIMM 1)
O DIMM 4 (Channel B DIMM 0)
P DIMM 2 (Channel B DIMM 1)
Q Front chassis fan header
R Chassis intrusion header
S Low Pin Count (LPC) Debug header
T Consumer IR emitter (output) header
U Consumer IR receiver (input) header
V Main power connector (2 x 12)
W Battery
X Piezoelectric speaker
Y SATA connectors (5)
Z Alternate front panel power LED header
AA Front panel header
BB BIOS Setup configuration jumper block
CC Standby power LED
DD Front panel USB 2.0 headers (4)
EE Intel P67 Express Chipset
FF S/PDIF out header
GG Front panel audio header
