Intel Desktop Board DP67BA Technical Product Specification
32
1.13.1.2 Wake-up Devices and Events
Table 8 lists the devices or specific events that can wake the computer from specific
states.
Table 8. Wake-up Devices and Events
These devices/events can wake up the computer… …from this state
Power switch S3, S4, S5
(
Note 1)
RTC alarm S3, S4, S5
(Note 1)
LAN S3, S4, S5
(Note 1)
USB S3
PME# signal S3, S4, S5
(Note 1)
WAKE# S3, S4, S5
(Note 1)
Consumer IR S3, S4, S5
(Note 2)
Notes:
1. S4 implies operating system support only.
2. Wake from S4 and S5 is recommended by Microsoft.
NOTE
The use of these wake-up events from an ACPI state requires an operating system that
provides full ACPI support. In addition, software, drivers, and peripherals must fully
support ACPI wake events.
1.13.2 Hardware Support
CAUTION
Ensure that the power supply provides adequate +5 V standby current if LAN wake
capabilities and Instantly Available PC technology features are used. Failure to do so
can damage the power supply. The total amount of standby current required depends
on the wake devices supported and manufacturing options.
The board provides several power management hardware features, including:
• Power connector
• Fan headers
• LAN wake capabilities
• Instantly Available PC technology
• Wake from USB
• PME# signal wake-up support
• WAKE# signal wake-up support
• +5 V Standby Power Indicator LED
• Wake from Consumer IR
LAN wake capabilities and Instantly Available PC technology require power from the
+5 V standby line.
