Intel Desktop Board DQ77CP Technical Product Specification
12
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Four USB 3.0 ports:
― Two USB 3.0 ports are implemented with stacked back panel connectors
(blue)
― Two front panel USB 3.0 ports are implemented through one internal
connector (blue)
• Eight USB 2.0 ports:
― Four ports implemented with stacked back panel connectors (black)
― Four front panel ports implemented through two dual-port internal headers
• Five Serial ATA (SATA) ports:
― Two SATA 6.0 Gb/s interface through the Intel Q77 Express Chipset with
Intel
®
Rapid Storage Technology RAID support (blue)
― Two internal SATA 3.0 Gb/s interfaces through Intel Q77 Express Chipset
with Intel Rapid Storage Technology RAID support (black)
― One internal eSATA 3.0 Gb/s interface (red)
• PS/2*-style keyboard/mouse port
• One serial port header
• One parallel port connector on the back panel
Expansion
Capabilities
•
One PCI Express 3.0 x16 add-in card connector
• One PCI Express 2.0 x1 bus add-in card connector from the PCH
• Two Conventional PCI bus add-in card connectors from the PCH
Note: PCI Express 3.0 is only supported by 3
rd
generation Intel Core processor
family processors
BIOS
• Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
• Support for PCI Express Revision 3.0
• Suspend to RAM support
• Wake on PCI, PCI Express, LAN, front panel, PS/2, serial, and USB ports
LAN Support
Gigabit (10/100/1000 Mb/s) LAN subsystem using the Intel
®
82579LM Gigabit
Ethernet Controller
Legacy I/O Control Nuvoton NCT6776D I/O controller for PS/2 port, serial port, parallel port, and
hardware management support
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Two fan sense inputs used to monitor fan activity
• Fan speed control
Intel
®
Security and
Manageability
Technologies
• Intel
®
vPro™ Technology
• Intel
®
Active Management Technology (Intel
®
AMT) 8.0
• Intel
®
Small Business Technology (Intel
®
SBT)
• Intel
®
Virtualization Technology (Intel
®
VT)
• Intel
®
Virtualization for Directed I/O (Intel
®
VT-d)
• Intel
®
Anti-Theft (Intel
®
AT)
