Intel Desktop Board DQ77CP Technical Product Specification
48
Table 11 lists the component-side connectors and headers identified in Figure 11.
Table 11. Component-side Connectors and Headers Shown in Figure 11
Item/callout f
rom Figure 11 Description
A Conventional PCI add-in card connector
B Conventional PCI add-in card connector
C PCI Express x1 add-in card connector
D PCI Express x16 add-in card connector
E 12 V processor core voltage connector (2 x 2 pin)
F Rear chassis fan header
G Processor fan header
H Front chassis fan header
I Chassis intrusion header
J LPC Debug header
K Main power connector (2 x 12)
L Intel MEBX reset header
M eSATA 3.0 Gb/s connector (red)
N Alternate front panel power/sleep LED header
O Front panel header
P SATA 3.0 connectors (black)
Q SATA 6.0 Gb/s connectors (blue)
R Front panel USB 3.0 connector (blue)
S Front panel USB 2.0 header
T Front panel USB 2.0 header
U Serial port header
V S/PDIF out header
W Front panel audio header
X Internal mono speaker header
