Intel DQ77MK Specification

Technical Reference
59
2.2.2.4.3 Power/Sleep LED Header
Pins 2 and 4 can be connected to a one- or two-color LED. Table 31 shows the
possible states for a one-color LED. Table 32 shows the possible states for a two-color
LED.
Table 31. States for a One-Color Power LED
LED State Description
Off Power off/sleeping
Steady Green Running
Table 32. States for a Two-Color Power LED
LED State Description
Off Power off
Steady Green Running
Steady Yellow Sleeping
NOTE
The colors listed in Table 31 and Table 32 are suggested colors only. Actual LED colors
are chassis-specific.
2.2.2.4.4 Power Switch Header
Pins 6 and 8 can be connected to a front panel momentary-contact power switch. The
switch must pull the SW_ON# pin to ground for at least 50 ms to signal the power
supply to switch on or off. (The time requirement is due to internal debounce circuitry
on the board.) At least two seconds must pass before the power supply will recognize
another on/off signal.
2.2.2.5 Alternate Front Panel Power/Sleep LED Header
Pins 1 and 3 of this header duplicate the signals on pins 2 and 4 of the front panel
header.
Table 33. Alternate Front Panel Power/Sleep LED Header
Pin Signal Name Description
1 POWER_LED_MAIN [Out] Front panel LED (main color)
2 Key (no pin)
3 POWER_LED_ALT [Out] Front panel LED (alt color)

Intel DQ77MK Specifications

General

Form Factor	Micro ATX
Socket	LGA 1155
Chipset	Intel Q77
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16	1
PCI Express x16 (x4 mode)	1
PCI Express x1	1
PCI	1
SATA 6Gb/s Ports	2
SATA 3Gb/s Ports	4
mSATA	1
USB 3.0 Ports	4
USB 2.0 Ports	8
Ethernet	Intel 82579LM Gigabit Ethernet
RAID Support	RAID 0, 1, 5, 10
Memory Types	DDR3 1333/1600
Video Outputs	DisplayPort
Audio	Realtek ALC892
