Intel Desktop Board D865GVHZ Product Guide
12
Table 2. Desktop Board Components
Label Description
A CD-ROM audio connector (ATAPI-style)
B Front panel audio header
C Rear chassis fan header
D 12 V processor core voltage connector
E Processor socket
F Processor fan header
G Intel 82865GV (GMCH)
H DIMM sockets
I Main power connector
J Diskette drive connector
K Primary IDE connector
L Secondary IDE connector
M Front chassis fan header
N BIOS configuration jumper
O Alternate power/sleep LED header
P Front panel header
Q Chassis intrusion header
R Serial ATA connectors
S USB 2.0 header
T Intel 82801EB (ICH5)
U Speaker
V Battery
W USB 2.0 header
X PCI bus add-in card connectors
Related Links
Go to the following links for the latest information about:
• Intel Desktop Board D865GVHZ, http://www.intel.com/design/motherbd
• Processors, http://support.intel.com/support/motherboards/desktop
• Audio software and utilities, http://www.intel.com/design/motherbd
• LAN software and drivers, http://www.intel.com/design/motherbd
