Intel G41 Simplified User Manual

Jumper Settings of G41
Pin# USB
1
Vcc: Power
2
Vcc: Power
3
D-
: Data - Signal
4
D-
: Data - Signal
5
D+: Data + Signal
6
D+: Data + Signal
7
GND: Ground
8
GND: Ground
9
KEY
10
NC
Pin# F_AUDIO
1
MIC+
2
GND
3
Vbias
4
AuD_Vcc(AVCC)
5
AuD_R_Out
6
R_Out Back
7
NC
8
Key
9
AuD_L_Out
10
L_Out
Back
Pin# F_PANEL
Pin2: power supply anode;Pin4:
GND
Power supply LED
Pin1: Power supply anode;
Pin3: LED Signal
HDD LED
Pin6, Pin8: Switch signal
Power supply switch
Pin5, Pin7: Reset switch
Reset Switch
Pin1, Pin4: Speaker output
Speaker Output
Jumper
Function
CPU_FAN
power the CPU cooling fan.
CLR_CMOS
short to clear CMOS settings.
SPEAKER
connect to speaker.
Pin assignment
1 3 5 7 9
2 4 6 8 10
