Intel H55 User Manual

ii
CHAPTER 1 INTRODUCTION OF INTEL H55 MOTHERBOARDS
1-1 FEATURES OF MOTHERBOARD................................................................1
1-1.1 SPECIAL FEATURES OF MOTHERBOARD .................................2
1-2 ITEM CHECKLIST.........................................................................................2
1-3 SPECIFICATION...........................................................................................3
1-4 LAYOUT DIAGRAM......................................................................................4
CHAPTER 2 HARDWARE INSTALLATION
2-1 CPU INSTALLATION ..................................................................................5
2-2 MEMORY MODULE INSTALLATION...........................................................6
2-3 EXPANSION SLOTS.....................................................................................7
CHAPTER 3 CONNCTORS, HEADERS & JUMPERS SETTING
3-1 CONNECTORS .............................................................................................7
3-2 HEADERS .....................................................................................................10
3-3 JUMPER SETTING .......................................................................................12
CHAPTER 4 USEFUL HELP
4-1 HOW TO UPDATE BIOS ..............................................................................13
4-2 TROUBLE SHOOTING .................................................................................13
TABLE OF CONTENT

Intel H55 Specifications

General

Socket	LGA 1156
Memory Type	DDR3
Memory Channels	Dual
Max Memory	16GB
Memory Standard	DDR3 1066/1333
PCI Express Revision	2.0
PCI Express x16	1
RAID Support	No
Chipset	Intel H55
Memory Slots	4
SATA Ports	6
Graphics Output	VGA, DVI, HDMI
Integrated Graphics	Yes (requires compatible CPU)
LAN	Gigabit Ethernet
Form Factor	ATX
Audio	HD Audio (Realtek ALC series, depending on manufacturer)
