Intel H61 Express User Manual

6
Jumper
Jumper
Name
Description
JBAT
CMOS RAM Clear Function Setting
3-pin Block
JP3
COM6 Header RS232/485/422 Function Select
6-pin Block
JP4
COM1 Header RS232 Power Select
6-pin Block
JP5
MINIPCI-E VCC 3.3V/SB 3.3VSelect
3-pin Block
CASE OPEN
Case Open Message Display Function
2-pin Block
Connectors
Connector
Name
Description
ATXPWR
ATX Power Connector
24-pin Block
ATX12V
ATX 12V Power Connector
4-pin Connector
COM3,COM4 &
COM1, COM2
Serial Port Connector
9-pin Connector
DVI-D
DVI-D Port Connector
24-pin Connector
VGA1
Video Graphic Attach Connector
15-pin Female
RJ-45 (from LAN 1)
RJ-45 LAN Connector
8-pin Connector
USB (from UL1,USB3)
USB 2.0 Port Connector
4-pin Connector
AUDIO1
Line In/ Line Out /MIC Audio
Connector
3 -phone Jack
SATA1/SATA2/
SATA3/SATA4/
SATAII Connector
7-pin Connectors

Intel H61 Express Specifications

General

Chipset	Intel H61 Express
Socket	LGA 1155
Memory Type	DDR3
Max Memory	16 GB
PCI Express Revision	2.0
USB Ports	Up to 10 USB 2.0 ports
SATA Ports	4 SATA 3Gb/s ports
RAID Support	No
LAN Speed	10/100/1000 Mbps
Memory Slots	2
Integrated Graphics	Yes
DirectX Support	DirectX 10.1 (depends on CPU)
