l 1000BASE-SX/LC on 850 nanometer optical fiber:
l Utilizing 50 micron multimode, length is 550 meters max.
l Utilizing 62.5 micron multimode, length is 275 meters max.
SFP+ and QSFP+ Devices
X710, XL710, and XXV710-Based Adapters
For information on supported media for X710/XL710/XXV710 based adapters, see the following link:
http://www.intel.com/content/dam/www/public/us/en/documents/release-notes/xl710-ethernet-controller-
feature-matrix.pdf
NOTES:
l Some Intel branded network adapters based on the X710/XL710 controller only support Intel
branded modules. On these adapters, other modules are not supported and will not function.
l For connections based on the X710/XL710 controller, support is dependent on your system
board. Please see your vendor for details.
l In all cases Intel recommends using Intel optics; other modules may function but are not val-
idated by Intel. Contact Intel for supported media types.
l In systems that do not have adequate airflow to cool the adapter and optical modules, you
must use high temperature optical modules.
l For XXV710 based SFP+ adapters Intel recommends using Intel optics and cables. Other
modules may function but are not validated by Intel. Contact Intel for supported media types.
82599-Based Adapters
NOTES:
l If your 82599-based Intel® Network Adapter came with Intel optics, or is an Intel® Ethernet
Server Adapter X520-2, then it only supports Intel optics and/or the direct attach cables listed
below.
l 82599-Based adapters support all passive and active limiting direct attach cables that com-
ply with SFF-8431 v4.1 and SFF-8472 v10.4 specifications.
Supplier Type Part Numbers
SR Modules
Intel DUAL RATE 1G/10G SFP+ SR (bailed) AFBR-703SDZ-
IN2
Intel DUAL RATE 1G/10G SFP+ SR (bailed) FTLX8571D3BCV-
IT
Intel DUAL RATE 1G/10G SFP+ SR (bailed) AFBR-703SDDZ-
IN1
