1-2 Specification
Spec Description
Design
∗ ATX form factor 6 layers PCB size: 30.5x24.5cm
Chipset
∗ Intel X58 Express Chipset
∗ Intel ICH10R chipset
CPU Socket
LGA 1366
∗ Supports the Intel® Core™ i7-965 processor Extreme Edition,
Intel® Core™ i7-940 processors and Intel® Core™ i7-920
processors.
∗ Support QPI up to 6.4 GT/s
Memory Sockets
∗ DDR3 Module sockets x 6
，
∗ Support 6 pcs DDR3 1600 /DDR3 1333MHz/ DDR3 1066
memory modules expandable to 24GB.
∗ Support Dual- channel / Three-channel function
Expansion Slots
∗ PCI-Express2.0 x16 slot 4pcs
∗ PCI-Express2.0 x4 slot 1pcs
∗ 32-bit PCI slot x 1pcs
Integrate IDE and
Serial ATA2 RAID
∗ The Intel ICH10R supports six internal Serial ATA ports for six
SATA devices with RAID0, RAID1, RAID5 and PAID10
function providing 3.0 Gb/sec data transfer rate.
∗ JMB363 supports PCI Bus Mastering, ATA PIO/DMA and the
ULTRA DMA 66 / 100/133 functions that deliver the data
transfer rate up to 133 MB/s for two IDE Devices and two
external Serial ATA ports providing 3.0 Gb /sec data transfer
rate for two serial ATA devices
Gigabit LAN
∗ Integrated Realtek RTL8111C PCI-E Gigabit LAN function.
∗ Supports Fast Ethernet LAN function provide 10Mb/100Mb/
1Gb /s data transfer rate.
8CH-Audio
∗ Realtek ALC888 Azalia 8-channel HD Audio Codec integrated
∗ Support 8-channel 3D surround & Positioning Audio
∗ Audio driver and utility included
BIOS
∗ AMI 8MB SPI Flash ROM
Multi I/O
∗ PS/2 keyboard and PS/2 mouse connectors
∗ ESATA connectors x2, SATA connectors x6
∗ Coaxial S/PDIF Out connector x1
∗ USB2.0 port x 8 and headers x2
∗ RJ-45 LAN connector x2
∗ Audio connector x1 (8-CH Audio)
∗ Floppy disk drive connector x1,Hard disk drive connector x1
∗ Serial Port headerx1
∗ HDMI-SPDIF header x1
∗ IR header x 1
