3.0 System Memory
Intel® NUC 11 Enthusiast Kit - NUC11PHKi7C and Intel® NUC 11 Enthusiast Mini PC -
NUC11PHKi7CAA have two DDR4 SO-DIMM sockets. Be sure to select memory
modules that meet these requirements:
• 1.2V low voltage memory
• 3200/2666MHz SO-DIMMs
• Max capacity - 64GB
• Non-ECC
Find compatible memory modules in the Intel Product Compatibility Tool
• NUC11PHKi7C
• NUC11PHKi7CAA
NOTE
If you plan to install only one memory module, install it in the upper
memory socket.
To install memory, follow these steps:
1. Observe the precautions in "Before You Begin" on page 5.
2. Turn off all peripheral devices connected to the computer. Turn off the
computer and disconnect the power cord.
3. Remove the computer’s top chassis cover and metal plate as described on
page 7 (section 2.0)
4. Align the small space at the bottom edge of the memory module with the key
in the socket.
