Intel NUC8i7HN - Page 12

12
Table 1. Feature Summary (continued)
Peripheral Interfaces
• USB 3.1 Gen 2 Ports:
― One Type-A port is implemented with an external front panel connector (blue), one
Type C port is implemented with an external front panel connnector
• USB 3.0 Ports:
― One port is implemented with an external front panel connector (yellow charging
capable)
― Four ports are implemented with external back panel connectors (blue)
― Two ports are implemented via an internal header (blue)
― 1 port implemented via the external back panel Type C connector
• USB 2.0 ports:
― Two ports via an internal common IO header (white)
― One port is reserved for the M.2 2230 Wireless module
• Consumer Infrared (CIR)
Expansion Capabilities
• Two M.2 connectors supporting M.2 2242 (1 slot) and M.2 2280 (key type M both slots)
modules
• One Full Size SDXC Slot
BIOS
• Intel
®
BIOS resident in the Serial Peripheral Interface (SPI) Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play, and
System Management BIOS (SMBIOS)
Instantly Available PC
Technology
• Suspend to RAM support
• Wake on PCI Express, LAN, front panel, CIR, and USB ports
LAN
Gigabit (10/100/1000 Mb/s) LAN subsystem using the Intel® Gigabit Ethernet Controller
I219-LM
Gigabit (10/100/1000 Mb/s) LAN subsystem using the Intel® Gigabit Ethernet Controller
I210-at
Hardware Monitor
Subsystem
Hardware monitoring subsystem, based on a ITE IT8987VG including:
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Two processor fan headers
• Fan sense input used to monitor fan activity
• Fan speed control
Wireless
Intel® Dual Band Wireless-AC 8265
• 802.11ac, Dual Band, Wi-Fi + Bluetooth 4.2
• Supports Intel® Wireless Display 6.0 (WiDi)
