Intel NUC8i7HN User Manual

Technical Reference
37
2.2.3 USB and I/O Headers
Figure 8 shows the location of the USB and I/O headers on the top-side of Intel NUC Kit
NUC8i7HN.
Figure 8. Headers and Connectors (Top)
Table 12. Headers and Connectors Shown in Figure 8
Item from
Figure 8
Description
A
Front panel USB 3.0 header (1.25 mm pitch) (blue)
B
Internal Common IO header (1.25 mm pitch) (white)
