11
2.
With the reserved length, start winding it onto the Rosette of the holder,
starting at the base and with the field connector latch facing down. After
approximately 5 turns of cable, plug the field connector into
the ONU inlet,
resulting in the image below:
Sentido da conexão
ONU
Trava do conector
ROSETA
90 cm
ONU
90 cm
Rosette
ONU
Direction of connection
Connector latch
