2.3. Cable installation
1. Three cables should be installed: drop compact fiber optic cable, network cable,
and ONU power cable. Starting with the compact drop cable, after installing the field
connector, reserve approximately 90 cm, as illustrated in the figure below:
Sentido da conexão
ONU
Trava do conector
ROSETA
90 cm
