t110W/t130W/t110Q/t130Q – Marine Satellite Television System
112
No. Item Description
1
Signal Level Display current signal level.
2
Antenna
status
- Setup: Displays whether or not the antenna is in SETUP
mode. The indicator shows “Blue” in the SETUP mode.
- Initial: Antenna or ACU is initialized.
- Search: Antenna is searching a target satellite.
- Track: Antenna is tracking the target satellite.
3
Restart Restart the antenna system.
4
Setup Enter SETUP mode.
5
Save Sat.
Save current satellite settings.
Bow offset will be adjusted and saved automatically.
6
Ant. Info Obtain current antenna information.
7
Account
Shortcut to User Management menu. Change login ID and
Password.
8
Logout Logout the ACU's internal HTML page.
Top Menus
Once you log in, the following information and menus are displayed.
1 3 4 5
6
7
8
2
