1. The antenna is searching for satellite [ 1 ].
2. The antenna is tracking satellite [ 1 ].
3. The antenna is winding /unwinding the cables in the antenna. The necessity of “unwrap”
is based on how far the ship has turned in one direction or the other.
4. The antenna is again tracking satellite [ 1 ].
5. Press the FUNCTION key to save current satellite information or abort and return to the
main display.
6. While the antenna is tracking satellite [ 1 ], press the RIGHT arrow key to display current
antenna information.
7. True azimuth [ 160.9] position of the antenna is the sum of ships heading 180.0
[ HDG ] and antenna relative [ 340.9 ]. Current IF signal level (AGC) is displayed .
•
will be only displayed when signal is strong enough to lock. VL indicates vertical
low band. VH: vertical High, HL: horizontal low, HH: horizontal high. Press the UP and
DOWN arrow keys to increase and decrease the LNB skew angle .
If the Up and Down arrow keys are unseen, press the OK key three times.
Monitoring Current Status
While POWER ON the Intellian t110W / t130W ACU displays the status of the antenna.
Various ACU displays may be shown according to the current status of the antenna.
SEARCH [
4
] ASTRA_1
[2] HOT_SPOT [3] ASTRA_3
TRACKING [
4
] ASTRA_1
[2] HOT_SPOT [3] ASTRA_3 Fn
TRACKING [
4
] ASTRA_1
[2] HOT_SPOT [3] ASTRA_3 Fn
TRACKING [
4
] ASTRA_1
[2] HOT_SPOT [3] ASTRA_3 Fn
TRACKING 19.2E ASTRA_1 AG C: 30 1
•
VL
AZ:160.9( 340.9) EL:29.0 SK: -21.1 Fn
SAVE CURRENT SAT INFO?
4
YES NO
ANT E NNA IS UNWRAPPING
