Intellian t110Q User Manual

t110W/t130W – Marine Satellite Television System
136
t130W Technical Specication
General
Approvals
CE – conforms to
FCC – veried to
EU Directive 89/336/EEC
CFR47:Part 15
Dimensions
Satellite antenna unit
Antenna dish diameter
Antenna control unit
165.2cm x 168.4cm(65" x 66.2")
125cm(49.2”)
43.1cm x 38cm x 4.4cm (17" x 15" x 1.7")
Weight
Satellite antenna unit
Antenna control unit
117kg (258lbs)
3.5kg (7.7lbs)
Environmental
Operating temperature range
Storage temperature range
Humidity limit
-25°C to +55°C (-13°F to +131°F)
-40°C to + 80°C (-40°F to + 176°F)
95% R.H
Power requirements 110/220V AC
Power consumption Typ. 50W, Max. 100W
Antenna system performance
Frequency Ku-band(10.7 to 12.75 GHz)
Minimum EIRP 40 dBW
Azimuth range -340° to +340°
Elevation range -15° ~ +120°
Roll/Pitch/Yaw ±25°/±15°/±8° @ 6 sec period
Turning rate up to 12°/sec and 15°/sec
2

Intellian t110Q Specifications
