Intellian t110W User Manual

t110W/t130W – Marine Satellite Television System
58
Search 3: a search pattern 3 will automatically be initiated when AGC falls below
the current tracking level threshold value. If the desired signal is found and above the
predened tracking level, the ACU will terminate Search 3 and go into TRACKING mode.
A search pattern will automatically be initiated when AGC falls below the current
threshold setting (indicates that satellite signal has been lost). Search is conducted
in a two-axis pattern consisting of alternate movements in azimuth (AZ) and elevation
(EL) as forming expanding square indicated as below diagram.
Elevation
(EL) Range
step size
Azimuth (AZ) Range
0.5˚
