v240C – Marine Satellite Communication System
138
No. Item Description
1
Signal Level Display current signal level.
2
Antenna
status
- Setup: Displays whether or not the antenna is in SETUP
MENU. The indicator shows “Blue” in the SETUP MENU.
- Initial: Antenna or ACU is initialized.
- Search: Antenna is searching a target satellite.
- Track: Antenna is tracking the target satellite.
3
TX Enable/
TX Disable
Displays whether or not the antenna is able to transmit the
data
4
Restart Restart the antenna system.
5
Setup Enter SETUP MENU.
6
Save Sat.
Save current satellite settings.
Bow offset will be adjusted and saved automatically.
7
Ant. Info Obtain current antenna information.
8
Account
Shortcut to User Management menu. Change login ID and
Password.
9
Logout Logout the ACU's internal HTML page.
Top Menus
Once you log in, the following information and menus are displayed.
1 3 4 5
6
7
8 9
2
