Installation Kit
Contains the items required for securing the antenna unit and ACU to the vessel.
ACU box components
Description Q'ty Size Remarks
Antenna Control Unit (ACU) 1 43.1 x 38 x 4.4cm Antenna Control Unit
Wi-Fi Antenna 1
ACU Side Bracket (Rack) 2 ACU to 19inch Rack
ACU Side Bracket (Table) 2 ACU to Table
USB Cable (A-A) 1 1.8m ACU to PC
D-Sub 9 pin Male Connector 2 ACU
N to F Adaptor 1 N(Male) to F(Female) Adaptor
USB Flash Drive 1
User Manual 1
RF Hazard Sticker 1 Radiation Safety Distance Label
Self-Tapping Screw 5 M4 x 16L
Bolt Kit for Table Mount Bracket
Sems Bolt 5 M3 x 12L
Flat Head Screw 10 M4 x 12L Bolt Kit for Rack Mount Bracket
Cable kit components
Description Q'ty Size Remarks
RG6 Cable 1 3m ACU to Modem
AC Power Cable 1 1.5m ACU Power (220V)
AC Power Cable (110V Plug) 1 1.5m ACU Power (110V)
PC Serial Cable 1 1.8m ACU to PC
iDirect Interface Cable 1 1.5m ACU to Modem
Modem Cable Pin Connection
