INSTALLING THE ANTENNA

Bolt Kit for Installation Box

Description Q'ty Size Remarks

Hex Bolt 4 M16x40L

Bolt Kit for Stable MountFlat Washer 4 M16

Spring Washer 4 M16

Hex Bolt (BUMAX) 9 M12x60L

Bolt Kit for PostLock Washer 17 M12

Nut (BUMAX) 9 M12

Hex Bolt 235 M6x35L Bolt for Radome Assembly

Hex Bolt 55 M6x35L Bolt for Radome Base Assembly

Flat Washer 580 M6(Ø18)

Washer & Nut for Radome &

Radome Base Assembly

Spring Washer 290 M6

Hex Bolt 10 M6x35L

Bolt Kit for Upper Radome Lift

Bracket

Flat Washer 20 M6(Ø18)

Spring Washer 10 M6

Hex Bolt (BUMAX) 9 M12x60L

Bolt Kit for Antenna MountingLock Washer 17 M12

Nut (BUMAX) 9 M12

Stable Mount Jig 1

Silicon 4

Silicon Gun 1

Loctite 263 1
