Intellian v240C User Manual

37
INSTALLING THE ANTENNA
In a different view, this
is the original position
(as is in section B).
Lifting straps cannot be
attached the CL arm in
this position.
As shown in Section C,
when the tap is moved,
lifting strap can be
attached to the CL arm.
4000mm Lifting straps
should be hooked onto
the I-bolts as shown left.
There should be 2 hooks
located on CL arm.
D.
E.
F.
30° Turn
