3. Press FUNCTION key to save current BOW OFFSET information or abort and return to the
main display. "Fn" will be displayed only if the antenna is in tracking menu.
4. Press RIGHT arrow key to display NBD, GPS and ship’s heading information.
5. NBD, GPS and ship’s heading information are shown.
NBD (Narrow Band Detection) IF tracking frequency : 1070000 KHz
Detected Band Width : 1000KHz
SIG (Signal Level ): 201
W (West ) / E (East) Longitude: 4.53 ° E
N (North) / S (South) Latitude: 52.22° N
HDG (Ship’s Heading) : 000.0 degree
LNB local oscillator(LO) frequency: 5150 MHz
6. Press RIGHT arrow key to display the below information.
Antenna part number, Antenna serial number and PCU / Stabilizer rmware version.
ACU part number, ACU serial number, ACU / Pol. Controller rmware version.
Press BACK Key to return to the rst page of the antenna current status.
7. Press RIGHT arrow key to display the USB FUNCTION.
When USB Memory is connected to USB port, the above screen will be displayed
With stored FWP le in USB Memory folder, ACU can be upgraded
UPGRADE FIRMWARE: ACU is upgraded with a FWP le in designated folder of USB
Memory
COPY LOG DATA: Copies data logs to USB Memory
Tracking & Heading
information
Antenna & ACU
versions
SAVE CURRENT SAT INFO ?
YES NO
Current tracking status
Save current satellite info
TRACKING 125.0E ASIA6H SIG:201
AZ:181.7( 181.7) EL: 47.3 SK: 02.0 Fn
NBD F:1070000 BW:1000 SIG:201
004.53E 52.22N HDG:000.0 L: 5150 Fn
V C1-241-P01 ANT. SERIAL 6.00/6.00
VP-T537 ACU SERIAL 3.00/1.00
[USB FUNCTION] SELECT USB FUNCTION
UPGRADE FIRMWARE
Select
USB
functions
To Next Page
