Intellian v80G User Manual

13
INTRODUCTION
Dual System
Conguration
CAUTION : Please ensure that the TX and RX cables are correctly terminated
in the power box inside the radome and on the ACU. Failure to connect these
correctly will cause system damage. Do not switch cables.
RS232 & RS422 Ethernet USBRS232ACU1 ACU2Console
NMEA
Heading
+ -
ANT1 ANT2 MODEM
RX MODEM Interface ACU Interface PC Interface
ANT1 ANT2 MODEM
TX
Satellite Modem
(Not supplied)
Antenna Control Unit
Modem
Interface
BUC
Interface
PC
InterfaceModem RX
Modem TX
NMEA
Antenna RXAntenna TX
Antenna
Tx
Antenna
Rx
Antenna
Tx
Antenna
Rx
AC 100 ~ 240V
(50~60Hz)
Ship’s Gyrocompass
(Not supplied)
Antenna
Unit 1
Antenna
Unit 2
AC 100 ~ 240V (50~60Hz)
Satellite Modem
Antenna
Control Unit 2
Antenna
Control Unit 1
Mediator
Ship’s
Gyrocompass
(Not supplied)
TX RX Interface
PC
PC
