Technical Specication
Technical Specication
General
Approvals
CE – conforms to EU Directive 89/336/EEC
FCC – veried to CFR47: Part 15
Dimensions
Satellite antenna unit 113 cm x 121 cm (44.6" x 47.5")
Antenna dish diameter 83cm (32.7”)
Antenna control unit 43.1cm x 38.1cm x 4.4cm (17” x 15” x 1.7”)
Weight
Satellite antenna unit 89.1 kg (196.4 lbs)
Antenna control unit 3.5kg (7.7 lbs)
Antenna system performance
Tx Frequency 14.0 ~ 14.5 GHz Ku-band
Tx Gain 40 dBi
Rx Frequency 10.7 ~ 12.75 GHz Ku-band
Rx Gain 37.6 dBi
Polarized Feed Cross-pol & Co-pol
Skew Control Automatic Skew-angle Control
Azimuth range Unlimited
Elevation range -10° ~ +110°
Cross-level range ±30°
Stabilization Accuracy 0.2° peak mis-pointing @ max ship motion condition
Max Ship’s motion ±25°roll, ±15° pitch, ±8°yaw@ 6 sec
Turning rate Up to 12°/ sec & 5°/ sec2
BUC 8W / 16W
Rack Mount Antenna Control Unit
Display 2 Line 40 Character Graphic VFD Module
Serial Interface RS232C (57600 bps 8, N, 1) / USB
Modem Interface Ethernet port / RS-232C / I/O ports
Remote Access RJ45, TCP/IP
Input Power 100 ~ 240V AC, 50 ~ 60Hz
Gyrocompass Interface NMEA2000 / NMEA0183

Intellian v80G Specifications

General

Brand	Intellian
Model	v80G
Category	Antennas
Language	English
