v80G – Marine Satellite Communication System
18
ACU (Antenna Control Unit)
ACU provides power to the antenna and Block Up Converter (BUC). The digital
Vacuum Fluorescent Display (VFD) allows for easy operation of the ACU, even in
the dark.
The functions of the ACU are as follows:
• System startup
• Setting the target satellite
• Editing satellite information
• Setting the antenna parameters
• Setting the antenna manual search
• Setting the LNB local frequency
• Setting radiation hazard or blockage zone
• Setting modem connections
• Setting GPS and Gyrocompass
• Display power status
• Performing real-time diagnostic tests
• Backup and restore the system settings
• Set up the interface with a PC
• Supports Wi-Fi ACU operation
• Recording antenna activities and rmware upgrade through USB
• Built-in web-based remote control management
• Front panel Management Ethernet port
Antenna Control Unit
Front panel
Rear panel
