39
INSTALLING THE ACU
Connecting the System without a Ship’s Gyrocompass
For a vessel where a ship’s gyrocompass is not installed or is difcult to connect,
the Intellian Gyro-Free satellite search function will be automatically enabled to
allow the antenna to lock onto the desired satellite without requiring an external
heading input.
The table below provides an example of the Gyro-Free satellite search algorithm.
The Search 1 or Search 3 satellite search pattern will be initiated according to the
existence of heading input and the setting of the heading device.
Search 1: The antenna will search for the target satellite by turning its azimuth
angle in a CCW(Counter Clockwise) direction until the antenna receives a
lock signal from the modem or until the DVB(Digital Video Broadcasting)
transponder of the target satellite is decoded by the antenna.
Search 3: The antenna will search for the target satellite by turning its azimuth angle
directly to the position calculated using the ship’s heading source and
lock onto the satellite.
Quick Setup Procedure
• Set the satellite with a DVB transponder as the target satellite.
• Select “No Device” as the heading device.
• The antenna will search for the target satellite by rotating the azimuth angle in a
CCW direction and will track the satellite when a lock signal is received from the
modem.
• Set the heading device as NMEA
- Enter the “Manual search” menu and press the “Function” key to save the current
settings. Intellian's ACU will automatically calculate and save the BOW offset.
- Upload the real TARGET satellite pre-congured from the library.
Setting of Heading Device
Existence of Heading Data No Device
NMEA / NMEA 2000
Ground Test
w/ Heading Data
Search 1 Search 3 Search 3
w/out Heading Data
Search 1 Search 1 Search 3
